2-SAFETYINFORMATION

(6A)Enginehoodsupportcaution-Stoptheengine

WARNING

Entanglementhazard!

Alwaysstoptheengineandengagethepark-

ingbrake,unlessotherwiseinstructedinthis

manual,beforecheckingand/oradjustingany

drivebeltorchain.

Failuretocomplycouldresultindeathorse-

riousinjury.

W0097A

Location:thissignislocatedonthesideoftheradiator.

Quantity:1

Partnumber:48018179

Thissignindicatesthatyoushouldstoptheenginebefore

openingthehood.

SMIL16MEX0013AA7

2-21
