3-CONTROLSANDINSTRUMENTS

Boomswingpedal

Thispedalisusedtoswingtheboomtotheright-hand

andleft-handdirection.

Pressthepedaltorearward(1)toswingtheboomtothe

right-handdirection.

Pressthepedaltoforward(2)toswingtheboomtothe

left-handdirection.

NOTICE:makeparticularattentionwhenswingtheboom

totheleft-handside:theattachmentmaycollidewiththe

cab.

SMIL16MEX1042BB15

3-11
