Case CX60C - Page 72

3-CONTROLSANDINSTRUMENTS
6.MODEpush-button
Thepush-button(6)beepsanddisplaysthesymbolon
thedisplaycorrespondingtothefollowingmodes:vent,
vent/foot,foot,foot/defrosting,vent.
WhenthedefrostingswitchisinONposition,thefresh
air/recirculationairpush-buttonturnstofreshairmode
andtheairconditioningsystemturnsON.
SMIL16MEX0571AA7
Mode
(A)(B)(C)
VentX
Vent-FootXX
FootX
Foot-
Defrosting
XX
Theoutletcontrollouvers(A),(B),and(C)allowstocon-
trolthedirectionofair.
Theoutletcontrollouverscanbeclosedoropened.
SMIL16MEX1047BA8
7.Freshairpush-button/8.Airrecirculation
push-button
Thepush-button(7)allowsexternalairtoentertheoper-
ator’scab.
Thepush-button(8)recycletheinternalairofthecab.
Indicationoftheairrecirculationwillappearonthedisplay
screen.
NOTE:changeairoccasionallywhenusingtheairrecir-
culationforalongtime.
SMIL16MEX0571AA9
3-18
