3-CONTROLSANDINSTRUMENTS

(9)Aircleanerwarninglight

ThislightturnsONwhenthelterofaircleanerisclogged.

Checkandcleanthelterorreplaceit.

SMIL16MEX3094AA17

(10)Overloadwarninglight(Optional)

Whenthemachineisoverload,theoverloadwarninglight

turnsONiftheoverloadswitchisONposition.

Reducethemachineload.

SMIL16MEX3094AA18

(11)DieselParticulateFilter(DPF)warninglight

ThislightturnsONorblinkswhentheregenerationis

needed,asdescribedinthefollowingtable.

Theconsequencesofdelayingregenerationare:

•

Poorperformancecausedbyincreasingexhaustgas

pressure

•

Higherfuelconsumption

•

Shorterlterlifetime

SMIL16MEX3094AA19

3-33
