101
16.2.5.2 Fully calculated installations
An
installer's
data
sheet
shall
be
displayed
beside
the
pump,
giving
the
following
information:
a)
the
pump
manufacturer's
data
sheets;
b)
a
schedule
listing
the
technical
data
specified
in
3.4.4.4;
c)
a
copy
of
the
installer's
pump
characteristics
sheet,
similar
in
presentation
to
Figure
H1;
d)
the
pressure
loss,
at
flow
Qmax.,
between
the
pump
outlet
and
the
most
hydraulically
remote
installation
'C'
gauge.
16.2.6 Electric switches and control panels
16.2.6.1 Alarm transmission
Where
water
flow
into
an
installation
initiates
an
automatic
alarm
to
the
fire
brigade
or
to
a
remote
control
station,
a
notice
to
that
effect
shall
be
fixed
adjacent
to
the
alarm
test
valve(s).
16.2.6.2 Diesel engine driven pump
The
alarms
specified
in
9.9.11
at
both
the
diesel
engine
controller
and
the
responsibly
manned
location
shall
be
marked
as
appropriate:
a)
diesel
fire
pump
failure
to
start;
b)
diesel
fire
pump
starter
switched
off;
c)
pump
running.
The
manually
operated
shut-down
mechanism
(see
9.9.7)
shall
be
labelled
as
follows:
'SPRINKLER
PUMP
SHUT-OFF'.
16.2.6.3 Electric motor driven fire pump
Each
switch
on
the
dedicated
power
feed
to
an
electric
sprinkler
fire
pump
motor
shall
be
labelled
as
follows:
'SPRINKLER
PUMP
MOTOR
SUPPLY
-
NOT
TO
BE
SWITCHED
OFF
IN
THE
EVENT
OF
FIRE'.
16.2.7 Testing and operating devices
All
valves
and
instruments
used
for
testing
and
operation
of
the
system
shall
be
appropriately
labelled.
Corresponding
identification
shall
appear
in
the
documentation.
1
17 Commissioning and acceptance tests
