43
User’s Manual
CellaVision
®
DM1200
(Cont'd)
The columns labeled 0 to 3 grade the morphology characteristics.
The rightmost column shows the percentage of RBCs in the overview image with
the characteristic in question. If the precharacterization is overridden by manual
characterization, the percentage is shown dimmed.
In the bottom right-hand corner of the RBC image there is a cross-shaped ruler that
represents 14 µm across. As the image magnification is increased, numbers will
appear at the ends of the ruler to indicate the scale in micrometers. The ruler can be
moved around the RBC image by moving the mouse pointer (in either zoom mode
or scroll mode) over the ruler, depressing the left mouse button and then by
dragging it to its desired placement.
The ruler will be placed back in the bottom right corner whenever the view is
changed.
The ruler shape can be toggled between the default cross shape and a line shape by
double-clicking on it. The shape will not change back to the cross when shifting
views.
A thin window frame appears around the ruler when the mouse pointer is moved
over it to indicate that the ruler can be moved or have its shape changed.
Note! The RBC precharacterization is not available for images captured on a
CellaVision Image Capture System .
Normal Green dot in column 0 indicates a normal level.
Slight
Red dot in column 1 indicates that the morphology is present at a
low level.
Moderate
Red dots in column 1-2 indicate that the morphology is present at a
moderate level.
Marked
Red dots in column 1-3 indicate that the morphology is present at a
high level.
