Estimating the Platelet Concentration Level
Images captured on a CellaVision DM System:
The PLT concentration level can be estimated by setting it to four levels:
Significantly decreased, Decreased, Normal or Increased directly from viewing the
image.
1. Use the entry fields to view all parts of the overview image.
2. Select Concentration level.
Images captured on a CellaVision Image Capture System:
The PLT concentration level can be estimated by setting it to four levels:
Significantly decreased, Decreased, Normal, or Increased directly from viewing
the image.
Select Concentration level.
Important
The area covered by each square may vary between different CellaVision Image
Capture Systems.
Excluding the Platelet Analysis
Click Exclude PLT Analysis to exclude PLT analysis results from the slide.
Entry field
The image has been manually captured
on a CellaVision Image Capture System
Square
