11.3 Mechanical Specifications
IDU Chassis Mechanical Specifications
1RU Chassis
Dimensions
Height: 44.5 mm
Width: 444.3 mm
Depth: 245 mm
Weight: 3 kg (empty)
2RU Chassis
Dimensions
Height: 88 mm
Width: 444.3 mm
Depth: 245 mm
Weight: 6 kg (empty)
IDU-XCVR
Connection
Coaxial cable up to 300 m, TNC connectors (male) to
IDU and XCVR.
IDU Card and Tray Weights
PDC
0.3 kg
RMC
0.34 kg
LIC
0.5 kg
TCC
1.5
Fans Drawer (1RU)
0.3 kg
Fans Drawer (2RU)
0.6 kg
Evolution XCVR Mechanical Specifications
XCVR Dimensions
Height: 230 mm
Width: 218 mm
Depth: 125 mm
Weight: 5.2 kg (excluding Branching)
Outdoor Branching
Housing Dimensions,
including XCVR
Height: 519 mm
Width: 600 mm
Depth: 632 mm
Weight: 50 kg (including branching for four channels)
Indoor XCVR Shelf
Height: 308 mm
Width: 481 mm
Depth: 231 mm
Long Haul Indoor
Terminals
2 channel system: 45 kg
4 channel system: 60 kg
6 channel system: 77 kg
8 channel system: 106 kg
