Evolution® IP-20LH Installation Guide
Ceragon Proprietary and Confidential Page 49 of 101
5.2 RMC/LIC Installation and Replacement
The installation and replacement procedures are identical for all RMC and LIC
types. For rules and guidelines about slot placement, refer to Slot Population
Guidelines on page 15.
5.2.1 Inserting an RMC or LIC into the Chassis
1 Carefully insert the new card.
Ensure that the card enters
the guides inside the chassis,
and gently press the card to
enter the internal connectors
without the use of excessive
force.
2 Make sure that the card
ejectors lock in the correct
position.
3 Fasten the two captive
screws manually.
