Ceragon Evolution IP-20LH - Standard Mount to Front Mount Conversion

Evolution® IP-20LH Installation Guide
Ceragon Proprietary and Confidential Page 36 of 101
2RU IDU Chassis in Rack - Standard Mount
4.2.1 Standard Mount to Front Mount Conversion
Loosen the four screws that hold the bracket to the chassis and retighten them
in the new position as shown below.
The same procedure is performed for the bracket at the opposite side of the
chassis.
1 Remove the four screws that hold
the bracket to the chassis.
