Ceragon Evolution IP-20LH - Removing the Filter Foam

Evolution® IP-20LH Installation Guide
Ceragon Proprietary and Confidential Page 58 of 101
5.5.2 Removing the Filter Foam
The filter tray is secured to the chassis by means of a captive screw (no
ejectors).
1 Unscrew the captive screw.
2 Remove the filter tray by pulling the captive screw.
