Pin #
Signal
Label on the
Twisted Pair
Type
64
IN - RING12
31
IN - TIP13
Ch13 Rx
TWISTED PAIR
65
IN - RING13
32
IN - TIP14
Ch14 Rx
TWISTED PAIR
66
IN - RING14
33
IN - TIP15
Ch15 Rx
TWISTED PAIR
67
IN - RING15
34
IN - TIP16
Ch16 Rx
TWISTED PAIR
68
IN - RING16
17
SHELL
-
SHIELD
18
SHELL
-
SHIELD
51
SHELL
-
SHIELD
52
SHELL
-
SHIELD
Synchronization Interface
RJ45
Pin no.
Description
1
T3_IN_N
2
T3_IN_P
3
1PPS_P
4
T4_OUT_N
5
T4_OUT_P
6
1PPS_N
7
ToD_P (or PPS_IN_P)
8
ToD_N (or PPS_IN_N)
