Chamberlain Elite EL2000 - Door Settings and Examples

Page 25
Sample: The System Controlling 1 Door (Next Page for Illustration)
Location Relay Relay Mode Relay Function Relay Activation Time (Seconds)
Front Door
1 Strike Unlocks Door 10 sec.
2 Shunt Bypasses/Signals Alarm 40 sec.
Device
Main Keypad
(REX) Exit Request
Door 1
3 Alarm Sounds a Siren 10 sec.
4 CCTV Activates Camera 10 sec.
Sample: The System Controlling 2 Doors and a Vehicle Gate (Next Page for Illustration)
Location Door No.
Door No.
Relay Relay Mode Relay Function Relay Activation Time (Seconds)
Front Door
Back Door
Gate Operator
1 Strike Unlocks Door 10 sec.
2 Control Turns on Security light 60 sec.
Device
Main Keypad and Postal Lock
Security Light
Wiegand Card Reader
Transmitter Buttons
Door 1
Door 2
Door 3
3 Strike Unlocks Door 10 sec.
4 Strike Opens Gate 10 sec.
Sample: The System Controlling Single Family Residence (Page 11 for Illustration)
Location Door No. Relay Relay Mode Relay Function Relay Activation Time (Seconds)
Driveway
Pedestrian Gate
In EL Model System
1 Strike Opens Vehicular Gate 10 sec.
2 Control Turns on Security Light 10 sec.
Device
Main Keypad and
(REX) Exit Request
CCTV
Wiegand Card Reader
Door 1
Door 2
Door 3
3 Strike Unlocks Pedestrian Gate 10 sec.
4 CCTV Activates Camera 10 sec.
Sample: The System Controlling 4 Doors (Page 27 for Illustration)
Location Relay Relay Mode Relay Function Relay Activation Time (Seconds)
Front Door (Entrance)
Front Door (Exit)
Back Door
Manager’s Door
1 Strike Unlocks Door 10 sec.
2 Strike Unlocks Door 10 sec.
Device
Main Keypad
Wiegand Keypad
Wiegand Card Reader
Wiegand Card Reader
Door 1
Door 2
Door 3
Door 4
3 Strike Unlocks Door 10 sec.
4 Strike Unlocks Door 10 sec.
Door No.
Sample: The System Controlling Multi-Resident Apartment (Page 12 for Illustration)
Location Relay Relay Mode Relay Function Relay Activation Time (Seconds)
Front Door (Entrance)
Vehicular Gate
Pool Gate
Front Door (Entrance)
1 Strike Unlocks Door 10 sec.
2 Strike Unlocks Door 10 sec.
Device
Main Keypad
Transmitter and REX Exit Device
Wiegand Card Reader
Siren
Door 1
Door 2
Door 3
Door 4
3 Strike Unlocks Door 10 sec.
4 Shunt Bypasses/Signals Alarm 30 sec.
Door No.
SetUP "Your Settings"
SetUP "Your Settings"
"Your" Door Settings
(See tables below for reference)
Device Location
Door
No.
Relay
Relay
Mode
Relay
Function
Relay Activation
Time (Seconds)
When
"Your Door Settings"
or
"Door 1,2,3 or 4"
are referenced throughout this
manual, this completed chart will outline how your unit will function.
