Quick Reference
81 41 Add or Edit a 81 # (card PIN code) # (facility code) (card type,
Full Function Card 26 or 30) # (schedule for door 1, 0-63) #
(schedule for door 2, 0-63) # (schedule for door
3, 0-63) # (schedule for door 4, 0-63) #
82 41 Add a Group of 82 # (card PIN code start range) # (card PIN code
Cards at Once end range) # (facility code) # (card type, 26 or 30)
# (0=deactivate, 1=activate) # (schedule for door
1, 0-63) # (schedule for door 2, 0-63) # (schedule
for door 3, 0-63) # (schedule for door 4, 0-63) #
name (0-20 characters) #
87 42 Activate or 87 # (card PIN code) # (facility code) # (card type,
Deactivate a Card
26 or 30) # (0=deactivate; 1=activate) # (0=don’t
use start; 1=use start) # (Start Date=yymmdd) #
(Start Time=hhmm) # (0=don’t use end; 1=use end)
# (End Date=yymmdd) # (End Time=hhmm) #
88 42 Delete a Card 88 # (card PIN code) # (facility code) #
(card type, 26 or 30) #
90 45 Add a Basic Transmitter 90 # (transmitter PIN code) # (facility code) #
(sequence number) # (ID number) # (button
number) #
91 46 Add or Edit a Full All Doors= 91 (transmitter PIN code) # (facility code) #
Function Transmitter 1 Full (sequence number) # (ID number) # (button
Access number) # (schedule for door 1, 0-63) # (schedule
for door 2, 0-63) # (schedule for door 3, 0-63) #
(schedule for door 4, 0-63) #
94 46 Add or Edit a Group of 94 # (transmitter PIN code start range)
Full Function Transmitters
# (transmitter PIN code end range) # (facility
code) # (sequence number) # (ID number)
# (button number) # (0=deactivate; 1=activate)
# (schedule for door 1, 0-63) # (schedule for door
2, 0-63) # (schedule for door 3, 0-63) # (schedule
for door 4, 0-63) #
95 47 Replace a Lost 95 # (transmitter PIN to change) # (facility code) #
Transmitter
(sequence number) # (ID number) # (button
number) # (new transmitter PIN) # (new facility
code) # (new sequence number) # (new ID number)
# (new button number) #
96 48 Verify a Transmitter 96 # (transmitter PIN code) # (facility code) #
(sequence number) # (ID number) # (button
number) #
98 48 Activate or Deactivate 98 # (transmitter PIN code) # (facility code) #
a Transmitter
(sequence number) # (ID number) # (button
number) # (0=deactivate; 1=activate) # (0=don’t
use start; 1=use start) # (Start Date=yymmdd)
# (Start Time=hhmm) # (0=don’t use end; 1=use
end) # (End Date=yymmdd) # (End Time=hhmm) #
100 47 Delete Transmitter 100 # (transmitter number) # (facility code) #
(sequence code) # (ID number) # (button
number) #
102 54 Configure "Door Held Disabled 102 # (alarm option; 0=disable, 1=enable until
Open” Alarm Feature
relay time expires, 2=enable until alarm clears) #
(relay group, 0000-1111) #
Order of relays is 4321
103 55 Configure "Door Forced Disabled 103 # (alarm option; 0=disable, 1=enable until
Open” Alarm Feature
relay time expires, 2=enable until alarm clears) #
(relay group, 0000-1111) #
Order of relays is 4321
104 55 Configure "Strikes Disabled 104 # (alarm option; 0=disable, 1=enable until
and Out” Alarm Feature
relay time expires, 2=enable until alarm clears) #
(relay group, 0000-1111) # Order of relays is 4321
