Troubleshooting Edge MAXX
6-10
WARNING
Only trained personnel with experience
in electrical or mechanical repair should
troubleshoot and repair the unit.
Troubleshooting
WARNING
Read the REPAIR chapter and make
sure that the power is disconnected
before doing any repairs.
ISSUE POSSIBLE CAUSE SOLUTION
(continued from previous page)
Unit Does Not Start
No Message Displayed
13. No voltage is available
to the DC power supply
modules.
Press and hold the START button. If
there is no indicator light on the power
supply card, check and replace circuit
breaker (CB4 or CB5), start switch
contacts or wiring, as necessary.
•
14. DC power supply is
faulty.
Press and hold the START button.
Check for 24VDC output.
•
Unit Does Not Start
Message reads:
CENTER STOP INTERLOCK/
!SERVICE OR CLEAR FAULT!
LEFT SIDE STOP/INTERLOCK/
!SERVICE OR CLEAR FAULT!
RIGHT SIDE STOP/
INTERLOCK/!SERVICE OR
CLEAR FAULT!
LEFT DOOR STOP/
INTERLOCK/!SERVICE OR
CLEAR FAULT!
RIGHT DOOR STOP/
INTERLOCK/!SERVICE OR
CLEAR FAULT!
1. A safety switch is open in
the starting circuit.
Locate and close any open interlock
switch.
•
Unit Does Not Start
Message reads:
CIRCUIT BREAKER TRIPPED
SERVICE OR CLEAR FAULT
INVERTER OR MOTOR OVER
-
LOAD
SERVICE OR CLEAR FAULT
(continued on next page)
1. A circuit breaker or motor
protector have tripped.
Locate the circuit breaker, and the
tripped motor protector and its compo
-
nents on the main electrical panel and
reset it. If the breaker continues to trip,
determine and correct the cause.
•
2. Check the motor thermo
-
stat connections, and the
temperature of the motor.
If the connections are
correct, and the motor sur
-
face is extremely hot, the
internal motor thermostat
is tripped.
When the motor has cooled, the ther
-
mostat will automatically reset. Check
the motor load. Call the factory Service
Department if the motor thermostat
trips repeatedly.
•
