Operating Principles Edge Maxx
5-2
Safety
The equipment described here has been
designed to work together to provide a safe and
reliable machine. Changing the equipment or
controls may cause a malfunction that could
injure someone. Do not bypass any of the safety
features or controls. Do not replace components
except with factory-approved repair parts.
Questions about the operation of the unit can be
answered by your local authorized CHICAGO
®
dealer, or by the Chicago Dryer Company service
department.
5.1 Electrical System
The electrical components of the unit are
divided into two areas:
Power System
Control System
The power system moves the rolls and ribbons,
activates the air valves, etc. The control system
decides when all these activities should occur.
Power System
Components in the power system are located
in the several places. The fused disconnect switch
is incorporated into the electrical connection box
door. If a line voltage transformer is required, it
is located inside the right endframe.
The power system includes:
Disconnect Switch and Fuses
Step-Down Transformers
Electrical Panel
•
•
•
•
•
