Chicago Dryer Edge MAXX - Page 87

Edge Maxx Operating Principles
5-11
Top View
PE45R
PE24
PE24
PX52
PX11
SPREADER RAIL
TRANSFER RAIL
PX32
PX28
PX31
PX27
PE45E
PE23
Figure 5-8: Photosensor and proximity sensor locations.
