Chino DB650 User Manual

[DB600] General Instruction Manual MODE 7
- 98 -
□
□□□
▲
SEL
↑ ↓ ▼
SEL
Gap
Output 2 gap
(PID control calculation)
Sets the gap for the output 2.
" "
to
"
□
"
-100.0 to 100.0 [%]
The display appears only when "Output 2 control system (MODE7)" is set to
" ".
Use the [

], [

] and [ENT] keys to set the gap for the output 2.
Use the [>] key to move the cursor to the right digit.
□□□
□□□
▲
SEL
↑ ↓ ▼
SEL
Dead band
Output 2
PID dead band /
output deadband
(PID control calculation)
Sets the PID dead band [PID control]/output dead band [two-position control] for the
output 2.
"
□□□
"
Function OFF [PID control]
* For the case of two-position control (P = 0.0%), operation is
performed with the output dead band 0.1% even if 0.0% is
set.
"
□□□
"
to
"
□□□
"
0.1 to 9.9 [%]
The display appears only when "Output 2 control system (MODE7)" is set to
" ".
Use the [

], [

] and [ENT] keys to set the PID dead band/output dead band for the
output 2.
Use the [>] key to move the cursor to the right digit.
The minimum value in two-position control (P = 0.0%) is 0.1%.
▲
SEL
↑ ↓ ▼
SEL
Heating/cooling
Output 2
control action
(PID control calculation)
Sets the control action for the output 2.
" "
Heating control
" "
Cooling control
The display appears only when "Output 2 control system (MODE7)" is set to
" ".
Use the [

], [

] and [ENT] keys to set the control action for the output 2.
□□□
▲
SEL
↑ ↓ ▼
SEL
Preset
Output 2
output preset
Sets the output preset for the output 2.
" "
to
"
□
"
-100.0 to 100.0 [%]
The display appears only when "Output 2 control system (MODE7)" is set to
" ".
Use the [

], [

] and [ENT] keys to set the output preset for the output 2.
Use the [>] key to move the cursor to the right digit.
[PID control]
Sets the output value immediately after starting control calculation. This output value
is output when control calculation is started in the PV = SV state such as PV start.
[P control]
Sets the output value for the case of PV = SV.
□□□
▲
SEL
↑ ↓ ▼
SEL
Split calculation
Split Direct
(split control calculation)
Sets the split Direct.
"
□□□
"
to
"
□□
"
0.0 to 60.0 [%]
The display appears only when "Output 2 control system (MODE7)" is set to
" ".
Use the [

], [

] and [ENT] keys to set the split Direct.
Use the [>] key to move the cursor to the right digit.
□
▲
SEL
↑ ↓ ▼
SEL
Split Reverse
(split control calculation)
Sets the split Reverse.
"
□□
"
to
"
□
"
40.0 to 100.0 [%]
The display appears only when "Output 2 control system (MODE7)" is set to
" ".
Use the [

], [

] and [ENT] keys to set the split Reverse.
Use the [>] key to move the cursor to the right digit.
