5-11-3 Transmission scale
This function is used to set the scale for transmission signal output (analog signal).
Set the transmission signal output range so that the transmission output ranges from 0% (transmission
scale zero) to 100% (transmission scale span).
To recorder
(Lower limit)
(Upper limit)
Measuring
range
Transmission scale range
Transmission signal output
range
