[DB600] General Instruction Manual
- 7 -
1-2-4 Model code list
 DB630
DB6④⑤⑥⑦⑧00⑪⑫0⑭
3: 48 x 48 size
0: PID control
Z: Z control
1: ON-OFF pulse output type
3: Current output type
5: SSR drive pulse output type
6: Voltage output type
0: None
1: ON-OFF pulse output type
3: Current output type
5: SSR drive pulse output type
6: Voltage output type
0: None
S: RS485 + 1 External input point [DI 1]
D: 5 External signal input points [DI1 to 5]
E: 5 Status event output points (open corrector
output) [EV 5 to 9]
- : None
P: Available
0: None
1: 2 Alarm event output points (mechanical relay
output) [EV1, 2]
*1
A: 100 to 240V AC
D: 24V AC/DC
*1 When specification with ⑦Control output 2, number of alarm event output point is only 1 point [EV 2].
④Size
⑤Control algorithm
⑥Control output 1
⑦Control output 2 (Option)
⑧Communications interface + 1 External signal
input point/
5 External signal input points/ 5 Status event
output points (Option)
⑪Programming function (Option)
⑫2 Aralm event output points (Option)
⑭Power voltage
