[DB600] General instruction manual
- 111 -
6 Detailed description for main function
6-1 Measuring range
The instrument adopts universal input to allow settings of various input types.
Set the input type most appropriate for the sensor and scale range to be used in actual operation. For
thermocouple and resistance thermometer, check the applicable standard before setting the input type.
Pay attention to the resistance thermometer "Pt100" which has three applicable standards.
Input type
Measuring range (°C)
Measuring range
Measuring range (°C)
Thermocouple
B
0.0 to 1820.0
DC voltage
20mV
±20.00mV
R
0.0 to 1760.0
100mV
±100.0mV
S
0.0 to 1760.0
5V
±5.000V
N
0.0 to 1300.0
10V
±10.000V
K1
-200.0 to 1370.0
Resistance
thermometer
Pt100_1
-200.0 to 850.0
K2
-200.0 to 500.0
Pt100_2
-200.0 to 200.0
E
-200.0 to 900.0
JPt100_1
-200.0 to 649.0
J
-200.0 to 1200.0
JPt100_2
-200.0 to 200.0
T
-200.0 to 400.0
Pt50
-200.0 to 649.0
U
-200.0 to 400.0
* For inputting direct current 4 to 20mA, attach an external
shunt resistor 250Ω (selling separately).
L
-200.0 to 900.0
W-WRe5-26
0.0 to 2310.0
W-WRe26
0.0 to 2310.0
Platinel II
0.0 to 1390.0
PtRh40-20
0.0 to 1880.0
Au-Pt
0.0 to 1000.0
Input type
Applicable standard
Thermo
couple
B, R, S, N, K, E, J, T
IEC584(1977,1982), JIS C 1602-1995, JIS C 1605-1995
U, L
DIN43710-1985
W-WRe26, Platinel II,
PtRh40-PtRh20, Au-Pt
ASTM E1751
WRe5-WRe26
ASTM E988
Resistance
thermometer
Pt100
IEC751(1995), JIS C 1604-1997
JPt100
JIS C 1604-1981, JIS C 1606-1986
Pt50
JIS C 1604-1981
