[DB600] General Instruction Manual
- 9 -
0: None
1: 2 Alarm event output points (mechanical relay
output) [EV1,2]
*3
2: 2 Alaem event output points (mechanical relay
output) [EV1,2]
*3
+ Heater disconnection
detection
*4
A: 100 to 240V AC
D: 24V AC/DC
*1 It can be specified when ⑥Control output 1 is “1”, “3”, “5” or “6”
*2 It can be specified when ⑥Control output 1 is “1”, “3”, “5” or “6” and ⑫2 Alarm event output points + Heater
disconnection detection is “0” or “1”.
*3 When specification with ⑦Control output 2, number of alarm event output points is only 1 point [EV 2].
*4 It can be specified when ⑥Control output 1 and ⑦Control output 2 are “1” or “5” and ⑩Remote signal input
+ 2 External signal input points is “0”, “5”, “6” or “7”.
However, if ⑥Control output 1 and ⑦Control output 2 are both “1” or “5”, it can be operated with Control
output 1.
⑫2 Alarm event output points + Heater
disconnection detection (Option)
