Introduction to the Control Chore-Tronics® 3 Control
10
MT2398C
Numeric Keypad
In a screen that has editable fields, select the value you want to edit (In this example: Set Temperature).
A Numeric Key Pad will be displayed. The name of the field will be displayed at the top of the Key pad.
Name of Field being edited.
Editable field
2
1
3
4
5
1. Scrolls the value up or down.
2. Removes the last number on the right.
3. Changes the entre from a positive to a negative number.
4. Removes the pop up with no changes to the value.
5. After you have made changes select "OK" to confirm the change. The pop up will disappear and the
change will be displayed in the field.
Figure 8. Numeric Keypad
In some editable fields you can enter text, if these fields are selected a Key Board will be displayed. If a
number is needed with the text, select the button labeled 123 on the Key Board and a Numeric Key Pad
will be displayed. To go back to the Key Board select the AZ button on the Numeric Key Pad. The OK
button will save your entry.
Toggle back and forth from Keyboard to Number Pad
using the
and the button.
Press "OK" to save entry
Figure 9. Toggling between Keyboard or Numeric Key Pad
