Control Installation Chore-Tronics® 3 Control
110
MT2398C
Once the screen has been adjusted, all assigned outputs should be tested individually by placing the
Manual Switches located on the Relay Box to the "MANUAL ON" position (See Figure 39). This will
also serve as a way of verifying that the proper output was wired to the proper Relay and/or the proper
Output Sticker was placed over the Toggle Switch.
Caution: Before turning any Switch to the on position, make sure all
people and objects are clear
of the device being turned on to avoid injury or damage.
Figure 39. Manual "On"
Switches in the Manual "On" position.
