Video Input panel
The Video Input panel, located on the projector side input panel (oper
ator side), has a variety of ports
that can supply alternative video content to the projector.
ID Port Description
A HDMI input 1 and HDMI input 2 Type A connector
HDMI v2.0 protocol supporting EDID 1.3 with HDCP v1.4 and 2.2
support
B SDI input 1, SDI input 2, SDI input 3,
and SDI input 4
75 ohm Micro-BNC Connector
Multi-R
ate SDI in accordance with SMPTE ST 259 (270 Mb/s), ST
292-1 (1.5 Gb/s), ST 424 (3.0 Gb/s), ST 2081-1 (6 Gb/s) and ST
2082-1 (12 Gb/s)
C DisplayPort (DP1 and DP2) Accepts digital video data from DisplayPort 1.2 input with HDCP 1.3
support.
D Christie Link port Not used.
E Software-Defined Video over Ethernet
(SDVoE) port
Not used.
F USB-C port Connects the projector touch panel.
CineLife+ User Guide 24
020-103073-10 R
ev. 1 (02-2023)
