Working with channels
Create channels to store customiz
ed projector settings for different inputs.
Using channels to set input signal parameters
Channels store customized projector settings for different video input signal parameters.
The following describes only the parameters associated with input signal selection to be configured by
the user. Additional parameter settings are required to fully describe a channel setup.
To create a new channel or edit the input video signal parameters for an existing channel, complete
the following steps.
1. In the left navigation menu, select Channel Setup.
2. Select + Add Channel to create a new channel or in the left panel, select a channel name to
select it for editing.
3. To define the input video signal parameters for the channel, complete the following fields.
Field name Description
Name The channel name
Input Type Select the input signal sources from one of the following:
•
HDMI - 1
• HDMI - 2
• HDMI 3D LR
• IMB
• SDI - 1
• SDI - 2
• SDI - 3
• SDI - 4
• SDI - Dual-Link (1,2)
• SDI - Dual-Link (3,4)
• SDI - Quad-Link (2SI)
• SDI - Quad-Link (SQ Div)
• SDI 3D LR (1,2)
• SDI 3D LR (3,4)
• SDI - Dual-Link 3D LR (1,2)(3,4)
• DisplayPort - 1
• DisplayPort - 2
• DisplayPort 3D LR
CineLife+ User Guide 69
020-103073-10 R
ev. 1 (02-2023)
