Christie 163-059105-XX - Displayport Video Source; Displayport Video Formats

Format Cables Frame rate (Hz) Sampling Bit-depth Notes
component at 6.0
Gb/s
(ST 2081-10)
mode 3
1920x1080 1 96, 100, 120 Y'C'
B
C'
R
/4:2:2:(4) 12 bpc HD 1080p
Y'C'
B
C'
R
component at
12.0 Gb/s
(ST 2082-10)
mode 2 structure
IV
1920x1080 1 96, 100, 120 Y'C'
B
C'
R
/RGB/
4:4:4
12 bpc HD 1080p
Y'C'
B
C'
R
/RGB
component at
12.0 Gb/s
(ST 2082-10)
mode 2 structure
III
1920x1080 1 96, 100, 120 Y'C'
B
C'
R
/RGB/
4:4:4:(4)
10 bpc HD 1080p
Y'C'
B
C'
R
/RGB
component at
12.0 Gb/s
(ST 2082-10)
mode 2 structure
II
DisplayPort video source
F
or the projector to accept digital video data, plug the DisplayPort source directly into the Video Input
panel.
The input configurations listed below are supported.
Input configuration Description
Single-input Enables connection of one DisplayPort cable. Supports both 2D and 3D frame
sequential tr
ansmission format. In this configuration the DisplayPort input supplies
the entire video raster.
Dual-input Enables connection of two DisplayPort cables. Supports both 2D and 3D frame
sequential transmission format.
DisplayPort video formats
The following image formats are supported b
y the DisplayPort inputs.
Frame rates also include fractional 1/1.001 frame rates.
Video Input panel
CineLife+ User Guide 40
020-103073-10 R
ev. 1 (02-2023)
