Single-input DisplayPort 1.2 image formats
The following single-input DisplayPort 1.2 image formats are supported on each of the DP 1.2 inputs.
Format Cables Frame rate (Hz) Sampling Bit-depth
HD 1280x720 1 24, 25, 30, 50, 60,
120
Y'C'
B
C'
R
/RGB/4:4:4 8/10/12bpc
1920x1080 1 24, 25, 30, 50, 60,
120
Y'C'
B
C'
R
/RGB/4:4:4 8/10/12bpc
2048x1080 1 24, 25, 30, 50, 60,
120
Y'C'
B
C'
R
/RGB/4:4:4 8/10/12bpc
4K 3840x2160 1 24, 25, 30, 50, 60 Y'C'
B
C'
R
/RGB/4:4:4 8/10bpc
4096x2160 1 24, 25, 30, 50, 60 Y'C'
B
C'
R
/RGB/4:4:4 8/10bpc
Single-input 3D DisplayPort 1.2 image formats
The following single-input 3D DisplayPort image formats are supported in frame sequential
transmission format. Frame rate is expressed per eye in the following table.
Format Cables Frame rate (Hz) Sampling Bit-depth
HD 1280x720 1 24, 25, 30, 50, 60 Y'C'
B
C'
R
/RGB/4:4:4 8/10/12bpc
1920x1080 1 24, 25, 30, 50, 60 Y'C'
B
C'
R
/RGB/4:4:4 8/10/12bpc
2048x1080 1 24, 25, 30, 50, 60 Y'C'
B
C'
R
/RGB/4:4:4 8/10/12bpc
4K 3840x2160 1 24, 25, 30 Y'C'
B
C'
R
/RGB/4:4:4 8/10bpc
4096x2160 1 24, 25, 30 Y'C'
B
C'
R
/RGB/4:4:4 8/10bpc
Dual-input 3D DisplayPort 1.2 image formats
The following dual-input 3D DisplayPort 1.2 image formats are supported. Frame rate is expressed per
eye in the following table.
Format Cables Frame rate (Hz) Sampling Bit-depth
HD 1280x720 2 24, 25, 30, 50, 60 Y'C'
B
C'
R
/RGB/4:4:4 8/10/12bpc
1920x1080 2 24, 25, 30, 50, 60 Y'C'
B
C'
R
/RGB/4:4:4 8/10/12bpc
2048x1080 2 24, 25, 30, 50, 60 Y'C'
B
C'
R
/RGB/4:4:4 8/10/12bpc
4K 3840x2160 2 24, 25, 30, 50, 60 Y'C'
B
C'
R
/RGB/4:4:4 8/10bpc
4096x2160 2 24, 25, 30, 50, 60 Y'C'
B
C'
R
/RGB/4:4:4 8/10bpc
Single-link DisplayPort PC image formats
The following single-link DisplayPort PC image formats are supported.
Format Cables Frame rate
(Hz)
Sampling Bit-depth
PC 1280x800 1 60 RGB 8bpc
Video Input panel
CineLife+ User Guide 41
020-103073-10 R
ev. 1 (02-2023)
