Christie 163-059105-XX - Series 4 Integrated Media Block (IMB) Video Formats

Specification Resolution Frame rate (per
eye)
Color format Bit-depth
SMPTE 2048-1-2011
Am1:2016
60.0 x 2
Series 4 Integrated Media Block (IMB) video formats
S4 Integr
ated Media Block (IMB) video format support is determined by the IMB make and model.
Refer to the associated IMB documentation to understand which of the following video signals are
supported.
All MPEG-2 content is converted in the media block to RGB 4:4:4 8-bit before play out.
MPEG-2 image formats
Format Resolution Max frame
rate 2D
Max frame
rate 3D
Min frame
rate
Bit depth
VGA 640 x 480 120.0 120.0 23.0 8-bits
525 4SIF 704 x 480 120.0 120.0 23.0 8-bits
525 SD 720 x 480 120.0 120.0 23.0 8-bits
4CIF 704 x 576 120.0 120.0 23.0 8-bits
625 SD 800 x 600 120.0 120.0 23.0 8-bits
SVGA 1024 x 768 79.6 79.6 23.0 8-bits
XGA 1024 x 768 79.6 79.6 23.0 8-bits
720p HD 1280 x 720 68.0 68.0 23.0 8-bits
4VGA 1280 x 960 51.0 51.0 23.0 8-bits
SXGA 1280 x 1024 47.8 N/A 23.0 8-bits
525 16SIF 1408 x 960 46.3 N/A 23.0 8-bits
16CIF 1408 x 1152 38.6 N/A 23.0 8-bits
4SVGA 1600 x 1200 32.6 N/A 23.0 8-bits
1080 HD 1920 x 1080 30.0 N/A 23.0 8-bits
MPEG-2 MXF interop 2D image formats
Format Resolution Max frame
rate 2D
Max frame
rate 3D
Min frame
rate
Bit depth
VGA 640 x 480 120.0 120.0 23.0 8-bits
525 4SIF 704 x 480 120.0 120.0 23.0 8-bits
525 SD 720 x 480 120.0 120.0 23.0 8-bits
4CIF 704 x 576 120.0 120.0 23.0 8-bits
625 SD 800 x 600 120.0 120.0 23.0 8-bits
