Format Cables Frame rate (Hz) Sampling Bit-depth Notes
component at
12.0 Gb/s
(ST 2082-10)
mode 1 structure
2
3840x2160 2 48, 50, 60 Y'C'
B
C'
R
/4:2:2 10 bpc 2160p
Y'C'
B
C'
R
/RGB
component at
12.0 Gb/s
(ST 2082-10)
mode 1 structure
1
3840x2160 2 24, 25, 30 Y'C'
B
C'
R
/RGB/
4:4:4
12 bpc 2160p
Y'C'
B
C'
R
/RGB
component at
12.0 Gb/s
(ST 2082-10)
mode 1 structure
3
3840x2160 2 24, 25, 30 Y'C'
B
C'
R
/4:2:2:(4) 12 bpc 2160p Y'C'
B
C'
R
component at
12.0 Gb/s
(ST 2082-10)
mode 1 structure
4
Dual-link 2D image formats
The following Dual-link (two cable) 2D SDI input formats are supported.
• Input 1 = SDI 1 and SDI 2
• Input 2 = SDI 3 and SDI 4
Format Cables Frame rate (Hz) Sampling Bit-depth Notes
HD 1920x1080 2 48, 50, 60 Y'C'
B
C'
R
/RGB/
4:4:4:(4)
10 bpc Y'C'
B
C'
R
/RGB
Component at
dual-link 3 Gb/s
(ST 425-3)
Structure II
1920x1080 2 48, 50, 60 Y'C'
B
C'
R
/RGB/
4:4:4
12 bpc Y'C'
B
C'
R
/RGB
component at
dual-link 3 Gb/s
(ST 425-3)
structure III
1920x1080 2 48, 50, 60 Y'C'
B
C'
R
/4:2:2 12 bpc Y'C'
B
C'
R
component at
dual-link 3 Gb/s
Video Input panel
CineLife+ User Guide 32
020-103073-10 R
ev. 1 (02-2023)
