Chroma 19020 User Manual

Calibration Procedure
7-21
1. Press START to output voltage.
2. Press numeric key 0 . ~ 9 to input actual resistance.
3. Press ENTER to confirm the input.
4. Press STOP to stop high voltage output.
5. Press ▼ to go to IRR 550GΩ OFFSET (40GΩ) calibration.
■ Connect a 40GΩ standard resistance in between the high voltage output terminal
(HV OUTPUT) and low potential terminal (RTN/LOW) of the channel to be calibrated
on the Tester.
IRR 550GΩ OFFSET (40GΩ) Calibration Screen:
CALIBRATION
IRR 550GΩ OFFSET(40GΩ)
NEXT CH
PREV CH
CHANNEL: 1
OUTPUT READING
1.000kV 40.5GΩ
STANDARD
40GΩ
LOAD=40GΩ
REMOTE
LOCK
CORR
ERROR
1. Press START to output voltage.
2. Press numeric key 0 . ~ 9 to input actual resistance.
3. Press ENTER to confirm the input.
4. Press STOP to stop high voltage output.
5. Press ▼ to go to IRR 550GΩ FULL (200GΩ) calibration.
■ Connect a 200GΩ standard resistance in between the high voltage output terminal
(HV OUTPUT) and low potential terminal (RTN/LOW) of the channel to be calibrated
on the Tester.
IRR 550GΩ FULL (200GΩ) Calibration Screen:
CALIBRATION
IRR 550GΩ FULL(200GΩ)
NEXT CH
PREV CH
CHANNEL: 1
OUTPUT READING
1.000kV 198GΩ
STANDARD
200GΩ
LOAD=200GΩ
REMOTE
LOCK
CORR
ERROR
