Chroma 19020 User Manual

Calibration Procedure
7-7
ACV 5kV 60Hz FULL (4kV) Calibration Screen:
CALIBRATION
ACV 5kV 60Hz FULL (4kV)
NEXT CH
PREV CH
CHANNEL: 1
OUTPUT READING
4.000kV 4.012kV
STANDARD
3.998kV
DEF=4kV
REMOTE
LOCK
CORR
ERROR
1. Press START to output voltage and read the data from the high voltage meter.
2. Press numeric key 0 . ~ 9 to input the reading of high voltage meter.
3. Press ENTER to confirm the input.
4. Press STOP to stop high voltage output.
5. Press ▼ to go to DCV 6kV AGC OFFSET (0.1kV) calibration.
7.4.2 DCV Calibration
■ Connect a DCV high voltage meter to the Tester with high voltage terminal
connected to HV OUTPUT and low voltage terminal connected to RTN/LOW of the
channel to be calibrated.
DCV 6kV AGC OFFSET(0.1kV) Calibration Screen:
CALIBRATION
DCV 6kV AGC OFFSET (0.1kV)
NEXT CH
PREV CH
CHANNEL: 1
OUTPUT READING
0.100kV 0.102kV
STANDARD
0.101kV
DEF=0.1kV
REMOTE
LOCK
CORR
ERROR
1. Press START to output voltage and read the data from the high voltage meter.
2. Press numeric key 0 . ~ 9 to input the reading of high voltage meter.
3. Press ENTER to confirm the input.
4. Press STOP to stop high voltage output.
5. Press ▼ to go to DCV 6kV AGC FULL (4kV) calibration.
