Chroma 19020 User Manual

Multi-Channel Sync Hipot Tester 19020/19020-4/19021/19021-4/19022/19022-4
User’s Manual
7-6
ACV 5kV 50Hz FULL (4kV) Calibration Screen:
CALIBRATION
ACV 5kV 50Hz FULL (4kV)
NEXT CH
PREV CH
CHANNEL: 1
OUTPUT READING
4.000kV 3.990kV
STANDARD
3.985kV
DEF=4kV
REMOTE
LOCK
CORR
ERROR
1. Press START to output voltage and read the data from the high voltage meter.
2. Press numeric key 0 . ~ 9 to input the reading of high voltage meter.
3. Press ENTER to confirm the input.
4. Press STOP to stop high voltage output.
5. Press ▼ to go to ACV 5kV 60Hz OFFSET (0.1kV) calibration.
ACV 5kV 60Hz OFFSET(0.1kV) Calibration Screen:
CALIBRATION
ACV 5kV 60Hz OFFSET (0.1kV)
NEXT CH
PREV CH
CHANNEL: 1
OUTPUT READING
0.100kV 0.103kV
STANDARD
0.104kV
DEF=0.1kV
REMOTE
LOCK
CORR
ERROR
1. Press START to output voltage and read the data from the high voltage meter.
2. Press numeric key 0 . ~ 9 to input the reading of high voltage meter.
3. Press ENTER to confirm the input.
4. Press STOP to stop high voltage output.
5. Press ▼ to go to ACV 5kV 60Hz FULL (4kV) calibration.
