Chroma 3300 - 8.5.2 LCR Data Output Format

Automatic Transformer Test System 3300/3302 User’s Manual
8-6
460 〜 469
AC resistance judgment 0: GO, 1: NG
470 〜 479
AC absolute impedance
judgment
0: GO, 1: NG
480 〜 484
Winding balance test
judgment
0: NO TEST, 1: GO, 2: NG
485 〜 488
Reserved
489 Low voltage/High
voltage
0: Low voltage only, 2: High voltage only, 3: From
high to low voltage, 4: From low to high voltage.
490 〜 499
Pin short-circuit
judgment
0: NO TEST, 1: GO, 2: NG
500 〜 508
End character code RedDrAgOn (ASCII)
<Note> The floating point used in this table is in INTEL format.
8.5.2 Data Output Format for LCR (3302 only)
The LCR is divided into LCR pure value and BIAS SCAN depending on if th ere is BIAS
SCAN.
8.5.2.1 LCR Pure Value Output Format
Except the SWEEP BIAS DISP menu, all of the rest menus use this format for output. Each
data has 32 bytes and outputs in string output.
Byte # Parameter Meaning
0 〜 1
Reserved
2
The primary
measurement parameter
Display the item of primary measurement parameter
(L, C, R, Z, Y, r (DCR)).
3 Reserved
4 〜 5
The unit of primary
measurement parameter
Display the unit of primary measurement parameter
(ex. mH, k Ω )
6 〜 13
The value of primary
m
easurement paramete
r
Display the value of primary measurement parameter,
which is one digit per byte for 8bytes in total.
14 Reserved
15 The secondary
measurement paramete
r
Display the item of secondary measurement parameter
(D, Q, R, G, X, θ ).
16 Reserved
17 〜 18
The unit of secondary
measurement parameter
Display the unit of secondary measurement parameter
(ex. m Ω )
19 〜 26
The unit of secondary
measurement parameter
Display the value of secondary measurement
parameter, which is one digit per byte for 8bytes in
total.
27 Reserved
28
Limits judgment 0: Parameter1, 2 PASS.
1: Parameter 1 LOW.
