Automatic Transformer Test System 3300/3302 Users Manual
1-2
1.2 Brief Specifications
Measurement Parameter:
First test parameters -- L, C, R,
Z
,
,
%, DCR, Turn-Ratio
Second test parameters -- Q, D, R,
θ
Basic Accuracy : Basic 0.1%
1kHz/1V rms
Measurement Range : L – .0001uH
9999.9H
C – .001pF
999.99mF
R – .0001
Ω
999.99M
Ω
Z
.0001
Ω
999.99M
Ω
Q – .0001
99999
D – .0001
99999
θ
90.00°
90.00°
DCR – .01m
Ω
99.999K
Ω
Np – .01
999.9Turn
Ns – .01
999.9Turn
(+
, —
Measurement Frequency : 20Hz to 1MHz
Measurement Voltage : 10mV to 2Vrms, each step 10mV
Equivalent Circuit : Series, Parallel
Zeroing Calibration : Open, Short
Turn-Ratio : 1kHz to 1MHz, 0.1V to 10Vrms
Notice :
The maximum input voltage of this instrument is 10 Vpesk. Be sure.
that the secondary voltage is below 10Vpeak.
Scan Test : Harmonize with scan control can test 20 points of
transformer scan test.
Interfaces : Memory Card, Scanner Interface. RS-232 interface,
Printer interface, Handler interface.
DCA control interface (Option)
