Nomenclature Description Characteristics CNG80 CNG100 CNG120 CNG160 CNG 200
A Mains RCCB Rated residual current
300mA to 500mA type B
(for each equipment) 125A 160A 200A 250A 315A
B1 and B2 Input/Output MCB type C 4P – 400Vac – 230Vac coil
type C
125A 160A 200A 250A 300A
C – OPTION A MCB type C 4P – 400Vac – 230Vac coil
type D
125A 160A 200A 250A 300A
C – OPTION B MCB type D 4P – 400Vac – 230Vac coil
type D
Depends on Power Transformer - two times of rated current of the transformer (take the same power as
rated power of the equipment)
250A 315A
- - -
Nomenclature Description Characteristics CNG80 CNG100 CNG120 CNG160 CNG 200
W1 (*) General rectifier line cable section
Configuration 1+0 / 1+1 RZ1-K 50 mm
2
70 mm
2
95 mm
2
120 mm
2
240mm
2
W2 (*) Individual rectifier line cable
section
RZ1-K 50 mm
2
70 mm
2
95 mm
2
120 mm
2
240mm
2
W3 (*) Individual rectifier line cable
section
RZ1-K Depends on Power Transformer - two times of rated current of the transformer (take the same power as
rated power of the equipment)
120mm
2
240mm
2
- - -
(*) A connection or cable distance less than 10 meters is recommended.
The sizing of the wires and protections has been calculated considering rated grid voltage (230Vrms phase-neutral) and rated power. Please
calculate the size of wire and protections in case that:
 The unit will be supplied permanently with an input voltage within 230Vrms,p-n – 20%
 The unit will be overloaded within 125% (during 10 minutes) or 150% (during 1 minute)
All figures are calculated for a maximum total cable length of 10 m between the equipment and the EUT.
