5. OPERATION
5.1. Safety
Before operating the equipment, check that the Protective Earth is properly
connected.
Check out the electrical installation in both sides (input and output) of the cabinet.
All wires shall be connected and secured before proceeding to the power supply
start-up.
When the equipment is turned off, the user has to wait at least 15 seconds before
turn it on again.
Before operating the equipment, check that all LIMITS from the equipment are
correct. Please take care that CNG equipment are bidirectional, this means that
the equipment can consume or inject current. The equipment can operate as a
source or as a load.
5.2. State Machine
The operation of the power supply is based on 6 different states (rectangles) and 6 transitions
(rhombus). Each state defines the behaviour and possible actions of the power supply:
