3.6. Configuration values of suitable terminal metric
Cables from electrical installation must have the suitable terminal metric value to connect on:
Nomenclature Characteristics CNG7.5 CNG10 CNG15 CNG20 CNG 30 CNG40 CNG50 CNG 60 CNG80 CNG100 CNG120 CNG160 CNG 200
Input Electrical
Connection
Terminal Metric Value M6 M6 M6 M6 M6 M8 M8 M8 M10 M10 M10 M10 M10
Output AC Electrical
Connection
Terminal Metric Value M6 M6 M6 M6 M6 M8 M8 M8 M10 M10 M10 M10 M10
Common Electrical
Connection
Terminal Metric Value M6 M6 M6 M6 M6 M8 M8 M8 M10 M10 M10 M10 M10
The values on all the tables in this document are valid for voltages of 230V.
