3. INSTALLATION AND WIRING RECOMMENDATIONS
Dear Client:
CINERGIA is committed with the continuous improvement of the Service and Technical Support offered
to you. For this reason, we are glad to provide you this guide of recommendations to install and start up
the unit where you will find advice and recommendations for the installation of the equipment that you
have just acquired.
We advise you to follow these instructions carefully and to contact us in case of any question or comment.
If the commissioning of the unit has been agreed with CINERGIA or one of our distributors, please follow
the recommendations in this document and once the installation is finished contact us to agree an
appointment.
3.1. Requirements and process to locate and fit in the equipment
 The room where the equipment will be placed must be clean and aired, leaving a space around
the equipment of 60 cm.
 Unpack and place the equipment in its final location. Check that input and output connections
are the same as the ones stated in the installation diagram. Terminal layout can differ from
attached diagram, please pay attention to the equipment labelling when doing the connection.
 Proceed to make and connect the installation according to the diagram and table below. It is
advisable to install all protection circuit breakers in a dedicated cabinet.
 Cables from electrical installation must have the suitable terminals to be connected on the
terminals used in the equipment. Cable used in the installation has to be flexible and its length
should be enough to allow moving the equipment without needing to disconnect it.
3.2. Installation features
 Cross cable section is recommended and based in the Spanish regulations. It is compulsory to
respect the Local and/or National Low Voltage Regulations so please check the recommended
values with respect to your local regulations.
 Recommended cross section with XLPW cable (cross linked polyethylene) is for a maximum total
installed cable length of 30 meters.
 If the Equipment Under Test is a power electronics device we recommend to size the neutral wire
to 200% of phase section.
 Cables trunks should be done over perforated shelves.
 The environmental conditions considered to calculate the recommended cross cable sections, in
accordance with the Spanish regulations, are:
o Ambient temperature: +40ºC.
o Correction factor to install all input(s)/output cables of each single equipment in the
same cable conduit.
o Correction factor to install the input(s)/output cables of the system (equipments in
parallel) in separate cable conduits.
 In case of installing fuses instead of moulded case circuit breakers, the fuses must be DIN gG/gL
type.
 Recommended protection sizes do not provide selectivity with those in the equipment. If
needed, choose a higher size than the recommended and size accordingly the cables.
