Protection elements (Q*):
 (Q1) Input thermal-magnetic circuit breaker or disconnector according to power of the
equipment.
 (Q2) Output disconnector.
 (Q4) AC/DC switch.
 (Q5) Parallel connection switch.
 (Q8) Bipolar/unipolar switch.
Connection elements (X*):
 (X1) Phase input terminal R.
 (X2) Phase input terminal S.
 (X3) Phase input terminal T.
 (X4) Neutral input terminal N.
 (X5) Earth connection terminal for main supply input ( ).
 (X6) Phase output terminal U.
 (X7) Phase output terminal V.
 (X8) Phase output terminal W.
 (X9) Neutral output terminal N.
 (X10) Earth connection terminal for EUT ( ).
 (X20) Negative output terminal U.
 (X21) Negative output terminal V.
 (X22) Negative output terminal W.
 (X11) DB9 female RS232 – RS485 connector for communications (optional).
 (X12) DB9 female CAN OUT (optional).
 (X13) RJ45 connector for MODBUS interface.
 (X14) Internal comms (not used).
 (X15) SUBD_15HD_FA_CI/SOP connector for analogic inputs and outputs.
 (X16) Terminals for external Emergency Power Off (EPO) button.
 (X17) SUBD_15HD_MA_CI/SOP connector for digital inputs and outputs.
In case of discrepancies between labelling and this manual instruction, the label
information will always prevail.
