b. The setpoints will appear with bars and can be modified by touching this bar
until it reaches the desired value or can also be modified touching the number
above the bar. It will go to the keyboard explained in the chapter 3.2. Keyboard.
c. To change the sign of the setpoint press this button. If it is positive will change
into negative and the other way around.
d. Once all the values are ready, press this Send button
The equipment needs to be in Run state to send the setpoints, otherwise
the values will not be sent.
If the user needs the converter to work as a load, the setpoint must be
with a negative sign. On the other hand, the converter will work as a
source with a positive sign.
e. By pressing Cancel, the LCD will go to the last tab where the user was without
sending any setpoint value.
