Enter Setup
1663 Barcode Scanner User Guide
3.2 CONNECTING VIA BLUETOOTH
®
DONGLE
3.2.1 CHANGE INTERFACE
Below is the procedure to configure the scanner before establishing a WPAN connection
via Bluetooth
®
dongle.
1) Read the “Enter Setup” barcode to enter the configuration mode.
2) Read the desired interface barcode –
“Activate Bluetooth
®
HID & Select Keyboard Type”
“Activate Bluetooth
®
SPP Slave Mode”
“Activate Bluetooth
®
SPP Master Mode”
3) Read the barcodes related to WPAN settings, such as Device Name Broadcasting,
Authentication & PIN Code, etc.
4) Read the “Update” barcode to exit the configuration mode.
5) The scanner will stay active for a specified period of time (2 minutes by default)
waiting for a connection request from the host (SPP Slave Mode) or trying to connect
to the host (HID or SPP Master Mode). Its CPU is running at full speed, and the LED is
flashing blue (On/Off ratio 0.5 s: 0.5 s).
Once connected, when out of range, the scanner will respond with three short beeps
(tone descending from high to low).
