204
Enter Setup
1663 Barcode Scanner User Guide
For the communication settings, select
“RS-232” and the correct COM port for
Direct USB Virtual COM interface.
Ignore the baud rate setting.
For the file option, click [Browse] to select
the target file for firmware update.
Click [OK].
5) After upgrading kernel, you will need to restart the scanner manually.
After upgrading the user program, the scanner will restart itself automatically once
the download is completely.
Note: Because 1663 supports the downloading of firmware via Direct USB Virtual COM
interface, the output interface will be set to the previously used one upon
completion of firmware upgrade.
USE BLUETOOTH
®
DONGLE
1) Refer to 3.2.3 Connect to Dongle for the target scanner to accept the connection
request from your computer.
2) Read the following barcodes in sequence to configure the scanner to use Bluetooth
®
SPP as download interface.
Enter Setup
Activate Bluetooth
®
SPP
Update
To Next Page
