6.6 PROGRAMMING EXAMPLES
6.6.1 EXAMPLE I
Extract data from the 10th character to the 19th character...
The editing format should be configured as follows:
1) Read the “Enter Setup” barcode to enter the Configuration Mode.
2) Read the “Configure Format 1” barcode.
3) Read the “Clear All” and “Code 128” barcodes for applicable code type.
4) Read the “Three Fields” barcode.
5) Read the “Divide Field 1 by Length” barcode, and set length to 9.
Field 1 data starts from the 1
st
character to the 9
th
character.
6) Read the “Divide Field 2 by Length” barcode, and set length to 10.
Field 2 data starts from the 10
th
character to the 19
th
character.
7) Read the “Start (Programming)” barcode to program the transmission sequence.
8) Read the “Field 2” barcode.
9) Read the “End” barcode to complete the transmission sequence setting.
10) Read the “End Programming Format” barcode to complete the setting of Editing Format 1.
11) Read the “Enable Format 1” barcode to apply Editing Format 1 to Code 128.
12) Read the “Update” barcode to exit the Configuration Mode.
