112
Enter Setup
1663 Barcode Scanner
U
ser Guide
4.1 CODABAR
*Enable
Disable
4.1.1 SECURITY LEVEL
Security Level renders more decoding accura
cy givi
ng consideration to barcod
es’ print
quality. Decide th
e security leve
l for reading CodaBar barcodes.
* High
Normal
4.1.2 START/STOP CH
ARACTERS SELECTION
Select one of the four different
start/stop character pairs –
* abcd/abcd
abcd/tn*e
ABCD/ABCD
ABCD/TN*E
123
125
