6.2.1 SELECT FORMAT TO CONFIGURE
Start Programming Format
Select one editing format (Format 1~5) and the parameters pertaining to the editing format can
then be configured – applicable code type, data length, matching string & location, start position,
field adjustment, total number of fields, field settings (field-dividing rule), additional fields, and
field transmission sequence.
Up to five different formats can be specified.
Configure Format 1
Configure Format 2
Configure Format 3
Configure Format 4
Configure Format 5
Note: Before completing the programming of an editing format, if any barcode for
parameters other than those pertaining to the editing format is read, the
programming process will be automatically aborted.
End Programming Format
After having configured all the desired parameters, you must read the “End Programming Format”
barcode, which can be located at the bottom of every even page in this chapter.
End Programming
Format
To Next Page
