4.10 GS1-128 (EAN-128)
*Enable
Disable
Note: GS1-128 barcodes can be decoded only when this setting is enabled. However, for
1660 with firmware version no later than 1.30, GS1-128 barcodes are taken as
Code 128 when this setting is disabled.
4.10.1 CODE ID TRANSMISSION
Decide whether to include the Code ID ("]C1") in the data being transmitted.
Transmit Code ID
*Do Not Transmit
4.10.2 FIELD SEPARATOR (GS CHARACTER)
Decide whether to apply a field separator (to convert the FNC1 control character to human
readable character).
Enable Field
Separator…
18) Read the barcode above to enable field separator.
19) Read the “
Hexadecimal Value” barcode on page 220 for the desired character string.
20) Read the “Validate” barcode to complete this setting.
Note: GS1-128 barcodes start with the
FNC1 control character to distinguish themselves
from other uses of Code 128. FNC1 is also used to separate data fields in the
GS1-128 barcodes.
To Next Page
