115
Update
Chapter 4
Change Symbology Settings
4.2.2 VERIFY CHECK DIGIT
Decide whether t
o verify the check digit. If incorrect
, the barcode will not be accept
ed.
Verify
Industrial
25
Check Digit
*Do Not Verify
4.2.3 TRANSMIT CHECK DIGIT
Decide whether to include the check digit in the data being transmitted.
*Transmit
I
ndustrial 25
Check Digit
Do Not Transmit
126
128
