RS30 Mobile Computer Reference Manual
Decode Timeout Sets the maximum time for the decoding process during a scan.
Configurable between 1 sec to 9 sec.
3 sec
Redundancy Level
Sets how many successful readings should be done before
linear barcodes such as Codabar, MSI, and Interleaved 2 of 5
can be decoded. Levels 1 to 4 available.
The readings needed for each level are as follows:
Level 1
The following barcodes must be
successfully read twice before being
decoded: Codabar
(Discrete 25), Interleaved 25.
Level 2
All barcodes must be successfully read
twice before being decoded.
Level 3
All barcodes must be successfully read
twice before being decoded, except for the
following which must be read three times:
MSI, Industrial 25 (Discrete 25),
Interleaved 25.
Level 4
All barcodes must be successfully read
three times before being decoded.
Level 1
Scan Angle Sets the scan angle for laser scan engine.
Wide Angle: 47° (Extended range laser reader is fixed at Wide Angle)
Narrow Angle: 35°
Wide
Angle
Scan Mode Sets the reader’s scanning behavior. Options available are
Continuous and Level modes.
Continuous: Used for continuous reading of barcodes. The scan engine
remains on when this mode is activated.
Level: Reads a barcode when the trigger is pressed.
Level
Timeout Between
Symbols
Sets the time for the barcode reader to resurrect its ability to
once more decode the barcode it just decoded.
Only applied in Continuous mode
1 sec
Addon Redundancy Functions when “auto-discriminate” is applied
addons. Decides the number of times of supplemental decoding
of the same barcode in order to
Configurable between 2 and 30.
10
