144
RS30 Mobile Computer Reference Manual
Transmit Check Digit
Decide whether to include the check digit in the data being
transmitted.
Disable
Convert To EAN-13 Convert a 14-character Interleaved 25 barcode into EAN-
13
if the following requirements are met:
The barcode must have a leading 0 and a valid EAN-
13
check digit.
Disable
GS1 DATABAR
GS1 DataBar-14 Enable
GS1 DataBar-14 Switch to enable GS1 DataBar-14 decoding. Enable
Convert to UPC/EAN Strips the leading ‘010’ of GS1
DataBar and converts the
barcode to EAN-13.
Disable
GS1 DataBar Limited Enable
GS1 DataBar Limited Switch to enable GS1 DataBar Limited decoding. Enable
GS1 DataBar Expanded Enable
GS1 DataBar Expanded Switch to enable GS1 DataBar Expanded decoding. Enable
MSI
MSI Enable
MSI Switch to enable MSI decoding. Enable
Length option Sets the length of the MSI symbols to decode.
One Fixed length (Length 1)
Two Fixed lengths (Length 1>Length 2)
Max / Min Length (range: 0-55; Length 1<Length 2)
Any Length
Max / Min
Length
(4-55)
Verify Check Digit One
check digit is mandatory for decoding MSI barcodes.
Select whether a second check digit should be verified. If the
check digits are incorrect, the barcode will not be accepted.
One Check Digit
Two Check Digits
One Check
Digit
Transmit Check Digit
Decide whether to include the check digit in the data being
transmitted.
Disable
Algorithm
When two check digits are set for verification, two choices
are available for the pair of check digits.
Modulo10 / Modulo11
Double Modulo 10
Double
Modulo 10
UPC/EAN
EAN-8 Enable
EAN-8 Switch to enable EAN-8 decoding. Enable
Convert to EAN-13 Checkbox to enable converting EAN-8 to EAN-13 format. Disable
